Freescale Semiconductor, Inc.
Enhanced Capture Timer
Timer Registers
Read anytime. Write anytime for output compare function. Writes to
these registers have no meaning or effect during input capture. All
timer input capture/output compare registers are reset to $0000.
BIT 7
6
PAEN
0
5
PAMOD
0
4
PEDGE
0
3
CLK1
0
2
CLK0
0
1
PAOVI
0
BIT 0
PAI
0
0
0
RESET:
PACTL — 16-Bit Pulse Accumulator A Control Register
$00A0
16-Bit Pulse Accumulator A (PACA) is formed by cascading the 8-bit
pulse accumulators PAC3 and PAC2.
When PAEN is set, the PACA is enabled. The PACA shares the input pin
with IC7.
Read: any time
Write: any time
PAEN — Pulse Accumulator A System Enable
0 = 16-Bit Pulse Accumulator A system disabled. 8-bit PAC3 and
PAC2 can be enabled when their related enable bits in
ICPACR ($A8) are set.
Pulse Accumulator Input Edge Flag (PAIF) function is
disabled.
1 = Pulse Accumulator A system enabled. The two 8-bit pulse
accumulators PAC3 and PAC2 are cascaded to form the
PACA 16-bit pulse accumulator. When PACA in enabled, the
PACN3 and PACN2 registers contents are respectively the
high and low byte of the PACA.
PA3EN and PA2EN control bits in ICPACR ($A8) have no
effect.
Pulse Accumulator Input Edge Flag (PAIF) function is enabled.
PAEN is independent from TEN. With timer disabled, the pulse
accumulator can still function unless pulse accumulator is disabled.
MC68HC912DG128 — Rev 3.0
Technical Data
