Enhanced Capture Timer
Timer Registers
PAOVI — Pulse Accumulator A Overflow Interrupt enable
0 = interrupt inhibited
1 = interrupt requested if PAOVF is set
PAI — Pulse Accumulator Input Interrupt enable
0 = interrupt inhibited
1 = interrupt requested if PAIF is set
BIT 7
6
0
0
5
0
0
4
0
0
3
0
0
2
0
0
1
PAOVF
0
BIT 0
PAIF
0
0
0
RESET:
PAFLG — Pulse Accumulator A Flag Register
$00A1
Read or write anytime. When the TFFCA bit in the TSCR register is set,
any access to the PACNT register will clear all the flags in the PAFLG
register.
PAOVF — Pulse Accumulator A Overflow Flag
Set when the 16-bit pulse accumulator A overflows from $FFFF to
$0000,or when 8-bit pulse accumulator 3 (PAC3) overflows from $FF
to $00.
This bit is cleared automatically by a write to the PAFLG register with
bit 1 set.
PAIF — Pulse Accumulator Input edge Flag
Set when the selected edge is detected at the PT7 input pin. In event
mode the event edge triggers PAIF and in gated time accumulation
mode the trailing edge of the gate signal at the PT7 input pin triggers
PAIF.
This bit is cleared by a write to the PAFLG register with bit 0 set.
Any access to the PACN3, PACN2 registers will clear all the flags in
this register when TFFCA bit in register TSCR($86) is set.
MC68HC912DG128 — Rev 3.0
Technical Data
Enhanced Capture Timer
