Register Descriptions
5.6.13.1 Fast Interrupt 1 Vector Address Low (FIVAL1)—Bits 15–0
The lower 16 bits of the vector address used for Fast Interrupt 1. This register is combined with FIVAH1
to form the 21-bit vector address for Fast Interrupt 1 defined in the FIM1 register.
5.6.14 Fast Interrupt 1 Vector Address High (FIVAH1)
Base + $D
Read
15
0
14
0
13
0
12
0
11
0
10
0
9
0
8
0
7
0
6
0
5
0
4
0
3
2
1
0
0
FAST INTERRUPT 1 VECTOR
ADDRESS HIGH
Write
0
0
0
0
0
0
0
0
0
0
0
0
0
0
RESET
Figure 5-16 Fast Interrupt 1 Vector Address High Register (FIVAH1)
5.6.14.1 Reserved—Bits 15–5
This bit field is reserved. Each bit must be set to 0.
5.6.14.2 Fast Interrupt 1 Vector Address High (FIVAH1)—Bits 4–0
The upper five bits of the vector address used for Fast Interrupt 1. This register is combined with FIVAL1
to form the 21-bit vector address for Fast Interrupt 1 defined in the FIM1 register.
5.6.15 IRQ Pending Register 0 (IRQP0)
Base + $E
Read
15
14
13
12
11
10
9
8
7
6
1
5
1
4
1
3
1
2
1
1
1
0
1
PENDING[16:2]
Write
1
1
1
1
1
1
1
1
1
1
RESET
Figure 5-17 IRQ Pending Register 0 (IRQP0)
5.6.15.1 IRQ Pending (PENDING)—Bits 16–2
These register bit values represent the pending IRQs for interrupt vector numbers 2 through 16. Ascending
IRQ numbers correspond to ascending bit locations.
•
•
0 = IRQ pending for this vector number
1 = No IRQ pending for this vector number
5.6.15.2 Reserved—Bit 0
This bit field is reserved. It must be set to 0.
