5.6.7.5
ADC B Conversion Complete Interrupt Priority Level
(ADCB_CC IPL)—Bits 5–4
This field is used to set the interrupt priority level for the ADC B Conversion Complete IRQ. This IRQ is
limited to priorities 0 through 2. It is disabled by default.
00 = IRQ disabled (default)
01 = IRQ is priority level 0
10 = IRQ is priority level 1
11 = IRQ is priority level 2
5.6.7.6
ADC A Conversion Complete Interrupt Priority Level
(ADCA_CC IPL)—Bits 3–2
This field is used to set the interrupt priority level for the ADC A Conversion Complete IRQ. This IRQ is
limited to priorities 0 through 2. It is disabled by default.
00 = IRQ disabled (default)
01 = IRQ is priority level 0
10 = IRQ is priority level 1
11 = IRQ is priority level 2
5.6.7.7
Programmable Interval Timer 2 Interrupt Priority Level
(PIT2 IPL)—Bits 1–0
This field is used to set the interrupt priority level for the Programmable Interval Timer 2 IRQ. This IRQ
is limited to priorities 0 through 2. It is disabled by default.
00 = IRQ disabled (default)
01 = IRQ is priority level 0
10 = IRQ is priority level 1
11 = IRQ is priority level 2
5.6.8
Vector Base Address Register (VBA)
Base + $7
Read
15
0
14
0
13
12
11
10
9
8
7
6
5
4
0
3
0
2
0
1
0
0
0
VECTOR_BASE_ADDRESS
Write
RESET1
0
0
0
0
0
0
0
0
0
0
0
1. The 56F8036 resets to a value of 0x0000. This corresponds to reset addresses of 0x000000.
Figure 5-10 Vector Base Address Register (VBA)
5.6.8.1
Reserved—Bits 15–14
This bit field is reserved. Each bit must be set to 0.
56F8036 Data Sheet, Rev. 6
72
FreescaleSemiconductor
