Register Descriptions
5.6.7
Interrupt Priority Register 6 (IPR6)
Base + $6
Read
15
0
14
0
13
0
12
0
11
10
9
8
7
6
5
4
3
2
1
0
ADCB_CC
IPL
ADCA_CC
IPL
PWM_F IPL
PWM_RL IPL
ADC_ZC IPL
PIT2 IPL
Write
RESET
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
Figure 5-9 Interrupt Priority Register 6 (IPR6)
5.6.7.1
Reserved—Bits 15–12
This bit field is reserved. Each bit must be set to 0.
5.6.7.2
PWM Fault Interrupt Priority Level (PWM_F IPL)—Bits 11–10
This field is used to set the interrupt priority level for the PWM Fault Interrupt IRQ. This IRQ is limited
to priorities 0 through 2. It is disabled by default.
00 = IRQ disabled (default)
01 = IRQ is priority level 0
10 = IRQ is priority level 1
11 = IRQ is priority level 2
5.6.7.3
Reload PWM Interrupt Priority Level (PWM_RL IPL)—Bits 9–8
This field is used to set the interrupt priority level for the Reload PWM Interrupt IRQ. This IRQ is limited
to priorities 0 through 2. It is disabled by default.
00 = IRQ disabled (default)
01 = IRQ is priority level 0
10 = IRQ is priority level 1
11 = IRQ is priority level 2
5.6.7.4
ADC Zero Crossing Interrupt Priority Level (ADC_ZC IPL)—Bits 7–6
This field is used to set the interrupt priority level for the ADC Zero Crossing IRQ. This IRQ is limited to
priorities 0 through 2. It is disabled by default.
00 = IRQ disabled (default)
01 = IRQ is priority level 0
10 = IRQ is priority level 1
11 = IRQ is priority level 2
56F8036 Data Sheet, Rev. 6
Freescale Semiconductor
71
