5.6.16 IRQ Pending Register 1 (IRQP1)
Base + $F
Read
15
14
13
12
11
10
9
8
7
6
1
5
1
4
1
3
1
2
1
1
1
0
1
PENDING[32:17]
Write
RESET
1
1
1
1
1
1
1
1
1
Figure 5-18 IRQ Pending Register 1 (IRQP1)
5.6.16.1 IRQ Pending (PENDING)—Bits 32–17
These register bit values represent the pending IRQs for interrupt vector numbers 17 through 32.
Ascending IRQ numbers correspond to ascending bit locations.
•
•
0 = IRQ pending for this vector number
1 = No IRQ pending for this vector number
5.6.17 IRQ Pending Register 2 (IRQP2)
Base + $10
Read
15
14
13
12
11
10
9
8
7
6
1
5
1
4
1
3
1
2
1
1
1
0
1
PENDING[48:33]
Write
1
1
1
1
1
1
1
1
1
RESET
Figure 5-19 IRQ Pending Register 2 (IRQP2)
5.6.17.1 IRQ Pending (PENDING)—Bits 48–33
These register bit values represent the pending IRQs for interrupt vector numbers 33 through 48.
Ascending IRQ numbers correspond to ascending bit locations.
•
•
0 = IRQ pending for this vector number
1 = No IRQ pending for this vector number
5.6.18 IRQ Pending Register 3 (IRQP3)
Base + $11
Read
15
14
13
12
11
10
9
8
7
6
1
5
1
4
1
3
1
2
1
1
1
0
1
PENDING[63:49]
Write
1
1
1
1
1
1
1
1
1
RESET
Figure 5-20 IRQ Pending Register 3 (IRQP3)
5.6.18.1 IRQ Pending (PENDING)—Bits 63–49
These register bit values represent the pending IRQs for interrupt vector numbers 49 through 63.
Ascending IRQ numbers correspond to ascending bit locations.
•
•
0 = IRQ pending for this vector number
1 = No IRQ pending for this vector number
56F8036 Data Sheet, Rev. 6
