5.6.5.1
Timer A, Channel 3 Interrupt Priority Level (TMRA_3 IPL)—
Bits 15–14
This field is used to set the interrupt priority level for the Timer A, Channel 3 IRQ. This IRQ is limited to
priorities 0 through 2. It is disabled by default.
•
•
•
•
00 = IRQ disabled (default)
01 = IRQ is priority level 0
10 = IRQ is priority level 1
11 = IRQ is priority level 2
5.6.5.2
Timer A, Channel 2 Interrupt Priority Level (TMRA_2 IPL)—
Bits 13–12
This field is used to set the interrupt priority level for the Timer A, Channel 2 IRQ. This IRQ is limited to
priorities 0 through 2. It is disabled by default.
•
•
•
•
00 = IRQ disabled (default)
01 = IRQ is priority level 0
10 = IRQ is priority level 1
11 = IRQ is priority level 2
5.6.5.3
Timer A, Channel 1 Interrupt Priority Level (TMRA_1 IPL)—
Bits 11–10
This field is used to set the interrupt priority level for the Timer A, Channel 1 IRQ. This IRQ is limited to
priorities 0 through 2. It is disabled by default.
•
•
•
•
00 = IRQ disabled (default)
01 = IRQ is priority level 0
10 = IRQ is priority level 1
11 = IRQ is priority level 2
5.6.5.4
Timer A, Channel 0 Interrupt Priority Level (TMRA_0 IPL)—
Bits 9–8
This field is used to set the interrupt priority level for the Timer A, Channel 0 IRQ. This IRQ is limited to
priorities 0 through 2. It is disabled by default.
•
•
•
•
00 = IRQ disabled (default)
01 = IRQ is priority level 0
10 = IRQ is priority level 1
11 = IRQ is priority level 2
56F8036 Data Sheet, Rev. 6
68
