4.4 Data Map
1
Table 4-4 Data Memory Map
Begin/End Address
Memory Allocation
X:$FF FFFF
X:$FF FF00
EOnCE
256 locations allocated
X:$FF FEFF
X:$01 0000
RESERVED
X:$00 FFFF
X:$00 F000
On-Chip Peripherals
4096 locations allocated
X:$00 EFFF
X:$00 8800
RESERVED
Reserved
X:$00 EFFF
X:$00 0800
X:$00 7FFF
X:$00 0040
RESERVED
On-Chip Data RAM2
4KB
X:$00 07FF
X:$00 0000
1. All addresses are 16-bit Word addresses.
2. This RAM is shared with Program space starting at P: $00 8000; see
Figure 4-1.
Program
Data
EOnCE
Reserved
Reserved
RAM
Peripherals
Reserved
RAM
Reserved
Dual Port RAM
Flash
Figure 4-1 Dual Port RAM
4.5 EOnCE Memory Map
Figure 4-5 lists all EOnCE registers necessary to access or control the EOnCE.
