F71872
7-0 LDN
R/W
00h 00h: Select FDC device configuration registers.
01h: Select UART 1 device configuration registers.
02h: Select UART 2 device configuration registers.
03h: Select Parallel Port device configuration registers.
04h: Select Hardware Monitor device configuration registers.
05h: Select KBC device configuration registers.
06h: Select GPIO device configuration registers.
07h: Select VID device configuration registers.
0ah: Select PME & ACPI device configuration registers.
7.10.2 ACPI and PME Configuration Registers
Device Enable Register Index 30h
Bit
7-1 Reserved
PME_EN
Name
R/W Default
Description
-
-
Reserved
0
R/W
0
0: disable PME.
1: enable PME.
PME Event Enable Register Index F0h
Bit
7
Name
Reserved
R/W Default
Description
-
-
Reserved
6
MS_PME_EN
KB_PME_EN
HM_PME_EN
PRT_PME_EN
UR2_PME_EN
UR1_PME_EN
R/W
0
PS/2 mouse PME event enable.
0: disable PS/2 mouse PME event.
1: enable PS/2 mouse PME event.
5
4
3
2
1
R/W
R/W
R/W
R/W
R/W
0
0
0
0
0
Keyboard PME event enable.
0: disable keyboard PME event.
1: enable keyboard PME event.
Hardware monitor PME event enable.
0: disable hardware monitor PME event.
1: enable hardware monitor PME event.
Parallel port PME event enable.
0: disable parallel port PME event.
1: enable parallel port PME event.
UART 2 PME event enable.
0: disable UART 2 PME event.
1: enable UART 2 PME event.
UART 1 PME event enable.
0: disable UART 1 PME event.
1: enable UART 1 PME event.
104
July, 2007
V0.28P
