F71872
0
FDC_PME_EN
R/W
0
FDC PME event enable.
0: disable FDC PME event.
1: enable FDC PME event.
PME Event Status Register Index F1h
Bit
7
Name
Reserved
R/W Default
Description
-
-
Reserved
6
MS_PME_ST
KB_PME_ST
HM_PME_ST
PRT_PME_ST
UR2_PME_ST
UR1_PME_ST
FDC_PME_ST
R/W
1
PS/2 mouse PME event status.
0: PS/2 mouse has no PME event.
1: PS/2 mouse has a PME event to assert. Write 1 to clear to be ready for next
PME event.
5
4
3
2
1
0
R/W
R/W
R/W
R/W
R/W
R/W
1
0
0
0
0
1
Keyboard PME event status.
0: Keyboard has no PME event.
1: Keyboard has a PME event to assert. Write 1 to clear to be ready for next
PME event.
Hardware monitor PME event status.
0: Hardware monitor has no PME event.
1: Hardware monitor has a PME event to assert. Write 1 to clear to be ready for
next PME event.
Parallel port PME event status.
0: Parallel port has no PME event.
1: Parallel port has a PME event to assert. Write 1 to clear to be ready for next
PME event.
UART 2 PME event status.
0: UART 2 has no PME event.
1: UART 2 has a PME event to assert. Write 1 to clear to be ready for next
PME event.
UART 1 PME event status.
0: UART 1 has no PME event.
1: UART 1 has a PME event to assert. Write 1 to clear to be ready for next
PME event.
FDC PME event status.
0: FDC has no PME event.
1: FDC has a PME event to assert. Write 1 to clear to be ready for next PME
event.
ACPI Control Register Index F4h
Bit
Name
R/W Default
Description
7
TS3
R/W
0
Set to 1 to enable keyboard or mouse can wakeup from S1 state, It must also
set EN_KBCWAKEUP and EN_MOWAKEUP register.
6
5
4
3
Reserved
-
-
-
Reserved
Reserved
-
Reserved
EN_KBCWAKEUP
EN_MOWAKEUP
R/W
R/W
0
0
Set to 1 to enable the Keyboard to wakeup system.
Set to 1 to enable the mouse to wakeup system.
