CY8C27x43 Final Data Sheet
3. Electrical Specifications
3.3.4
DC Analog Output Buffer Specifications
The following tables list guaranteed maximum and minimum specifications for the voltage and temperature ranges: 4.75V to 5.25V
and -40°C ≤ TA ≤ 85°C, or 3.0V to 3.6V and -40°C ≤ TA ≤ 85°C, respectively. Typical parameters apply to 5V and 3.3V at 25°C and
are for design guidance only.
Table 3-8. 5V DC Analog Output Buffer Specifications
Symbol
VOSOB
Description
Min
Typ
Max
Units
mV
Notes
Input Offset Voltage (Absolute Value)
–
3
12
–
TCVOSOB
VCMOB
Average Input Offset Voltage Drift
Common-Mode Input Voltage Range
–
+6
–
µV/°C
0.5
Vdd - 1.0
V
ROUTOB
Output Resistance
Power = Low
–
–
1
1
–
–
Ω
Ω
Power = High
VOHIGHOB
High Output Voltage Swing (Load = 32 ohms to Vdd/2)
Power = Low
0.5 x Vdd + 1.3
0.5 x Vdd + 1.3
–
–
–
–
V
V
Power = High
VOLOWOB
Low Output Voltage Swing (Load = 32 ohms to Vdd/2)
Power = Low
Power = High
–
–
–
–
0.5 x Vdd - 1.3
0.5 x Vdd - 1.3
V
V
ISOB
Supply Current Including Bias Cell (No Load)
Power = Low
–
1.1
2.6
–
5.1
8.8
–
mA
mA
dB
Power = High
–
PSRROB
Supply Voltage Rejection Ratio
60
Table 3-9. 3.3V DC Analog Output Buffer Specifications
Symbol
VOSOB
Description
Min
Typ
Max
Units
Notes
Input Offset Voltage (Absolute Value)
–
3
12
mV
µV/°C
V
TCVOSOB
VCMOB
Average Input Offset Voltage Drift
Common-Mode Input Voltage Range
–
+6
-
–
0.5
Vdd - 1.0
ROUTOB
Output Resistance
Power = Low
–
–
1
1
–
–
Ω
Ω
Power = High
VOHIGHOB
High Output Voltage Swing (Load = 1k ohms to Vdd/2)
Power = Low
Power = High
0.5 x Vdd + 1.0
0.5 x Vdd + 1.0
–
–
–
–
V
V
VOLOWOB
Low Output Voltage Swing (Load = 1k ohms to Vdd/2)
Power = Low
Power = High
–
–
–
–
0.5 x Vdd - 1.0
0.5 x Vdd - 1.0
V
V
ISOB
Supply Current Including Bias Cell (No Load)
Power = Low
0.8
2.0
–
2.0
4.3
–
mA
mA
dB
Power = High
–
PSRROB
Supply Voltage Rejection Ratio
60
