3. Electrical Specifications
3.3.3
DC Operational Amplifier Specifications
The following tables list guaranteed maximum and minimum specifications for the voltage and temperature ranges: 4.75V to 5.25V
and -40°C ≤ TA ≤ 85°C, or 3.0V to 3.6V and -40°C ≤ TA ≤ 85°C, respectively. Typical parameters apply to 5V and 3.3V at 25°C and
are for design guidance only.
The Operational Amplifier is a component of both the Analog Continuous Time PSoC blocks and the Analog Switched Cap PSoC
blocks. The guaranteed specifications are measured in the Analog Continuous Time PSoC block. Typical parameters apply to 5V at
25°C and are for design guidance only.
Table 3-6. 5V DC Operational Amplifier Specifications
Symbol
VOSOA
Description
Input Offset Voltage (absolute value)
Power = Low, Opamp Bias = High
Power = Medium, Opamp Bias = High
Power = High, Opamp Bias = High
Average Input Offset Voltage Drift
Min
Typ
Max
Units
Notes
–
–
–
–
1.6
10
8
mV
1.3
1.2
7.0
mV
mV
7.5
µV/oC
TCVOSOA
IEBOA
35.0
Input Leakage Current (Port 0 Analog Pins)
Input Capacitance (Port 0 Analog Pins)
Common Mode Voltage Range
–
–
20
–
pA
Gross tested to 1 µA.
Package and pin dependent. Temp = 25oC.
CINOA
4.5
9.5
pF
V
VCMOA
0.0
0.5
–
–
Vdd
The common-mode input voltage range is mea-
sured through an analog output buffer. The
specification includes the limitations imposed
by the characteristics of the analog output
buffer.
Common Mode Voltage Range (high power or high
opamp bias)
Vdd - 0.5
CMRROA
Common Mode Rejection Ratio
Power = Low
–
–
–
–
dB
dB
Specification is applicable at high power. For all
other bias modes (except high power, high
opamp bias), minimum is 60 dB.
60
60
60
Power = Medium
Power = High
GOLOA
Open Loop Gain
Specification is applicable at high power. For all
other bias modes (except high power, high
opamp bias), minimum is 60 dB.
Power = Low
60
60
80
Power = Medium
Power = High
VOHIGHOA
VOLOWOA
ISOA
High Output Voltage Swing (internal signals)
Power = Low
Vdd - 0.2
Vdd - 0.2
Vdd - 0.5
–
–
–
–
–
–
V
V
V
Power = Medium
Power = High
Low Output Voltage Swing (internal signals)
Power = Low
–
–
–
–
–
–
0.2
0.2
0.5
V
V
V
Power = Medium
Power = High
Supply Current (including associated AGND buffer)
Power = Low, Opamp Bias = Low
Power = Low, Opamp Bias = High
Power = Medium, Opamp Bias = Low
Power = Medium, Opamp Bias = High
Power = High, Opamp Bias = Low
Power = High, Opamp Bias = High
Supply Voltage Rejection Ratio
–
150
300
600
1200
2400
4600
–
200
400
800
1600
3200
6400
–
µA
µA
µA
µA
µA
µA
dB
–
–
–
–
–
PSRROA
60
0V ≤ VIN ≤ (Vdd - 2.25) or
(Vdd - 1.25V) ≤ VIN ≤ Vdd.
