CY7C9689
Table 6. Receiver Output Bus Signal Map
[1]
Receiver Decoder Mode
Encoded 8-bit
RXDATA Bus Output Bit Character Stream
Pre-encoded 10-bit
Character Stream
Encoded 10-bit
Character Stream
Pre-encoded 12-bit
Character Stream
[8]
[9]
RXSC/D
RXDATA[0]
RXSC/D
RXDATA[0]
RXDATA[1]
RXDATA[2]
RXDATA[3]
RXDATA[4]
RXDATA[5]
RXDATA[6]
RXDATA[7]
RXCMD[3]
RXCMD[2]
RXCMD[1]
RXCMD[0]
VLTN
RXSC/D
[10, 11]
[10, 12]
RXD[0]
RXDATA[0]
RXDATA[1]
RXDATA[2]
RXDATA[3]
RXDATA[4]
RXDATA[5]
RXDATA[6]
RXDATA[7]
RXDATA[8]
RXD[0]
RXDATA[1]
RXD[1]
RXD[2]
RXD[3]
RXD[4]
RXD[5]
RXD[6]
RXD[7]
RXD[8]
RXD[9]
RXD[1]
RXD[2]
RXD[3]
RXD[4]
RXD[5]
RXD[6]
RXD[7]
RXD[8]
RXD[9]
RXDATA[2]
RXDATA[3]
RXDATA[4]
RXDATA[5]
RXDATA[6]
RXDATA[7]
RXDATA[8]/RXCMD[3]
RXDATA[9]/RXCMD[2]
RXCMD[1]
[9]
RXDATA[9]
[12]
RXCMD[1]
RXCMD[0]
VLTN
RXD[10]
RXCMD[0]
RXD[11]
VLTN
Static Discharge Voltage .......................................... > 2001V
(per MIL-STD-883, Method 3015)
Maximum Ratings
(Above which the useful life may be impaired. For user guide-
lines, not tested.)
Latch-Up Current.................................................... > 200 mA
Storage Temperature ................................–65×C to +150×C
Ambient Temperature with (Power Applied)–55×C to +125×C
Supply Voltage to Ground Potential ............... –0.5V to +6.5V
Operating Range
Ambient
Range
Commercial
Industrial
Temperature
0°C to +70°C
–40°C to +85°C
V
DD
5.0V ± 10%
5.0V ± 10%
DC Voltage Applied to Outputs ................–0.5V to V +0.5V
DD
Output Current into TTL Outputs (LOW)......................30 mA
DC Input Voltage......................................–0.5V to V +0.5V
DD
Notes:
8. When BYTE8/10 is HIGH, received bit order is decoded form the serial stream and presented (MSB to LSB) at RXDATA[7,6,5,4] and RXDATA[3,2,1,0] or
RXCMD[3,2,1,0] as indicated by RXSC/D.
9. When BYTE8/10 is LOW, received bit order is decoded form the serial stream and presented (MSB to LSB) at RXDATA[8,7,6,5,4] and RXDATA[9,3,2,1,0] or
RXCMD[1,0] as indicated by RXSC/D
10. First bit shifted into the receiver.
11. When ENCBYP is LOW and BYTE8/10 is HIGH, the received bit order is (LSB to MSB) RXD[0,1,2,3,4,5,6,7,8,9].
12. When ENCBYP is LOW and BYTE8/10 is LOW, the received bit order is (LSB to MSB) RXD[0,1,2,3,4,5,6,7,8,9,11,10].
