AIS Baseband Processor
CMX910
Sleep_Sample register: 16-bit write only.
C-BUS Address $12
All bits cleared to 0 on reset.
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
Bit:
Reserved, set to 00000
Sleep sample value
The Sleep_Sample register holds the sample value at which the CMX910’s Rx1 or Rx2 circuits
enter sleep mode during an inactive slot.
Wakeup_Sample register: 16-bit write only.
C-BUS Address $13
All bits cleared to 0 on reset.
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
Bit:
Reserved, set to 00000
Wakeup sample value
The Wakeup_Sample register holds the sample value at which the CMX910’s Rx1 or Rx2 circuits
leave sleep mode after an inactive slot, in time to detect a training sequence in the next slot.
Slot_Sample_UTC1PPS register: 32-bit read only.
C-BUS Address $14
All bits cleared to 0 on reset.
31
0
30
0
29
0
28
0
27
26
10
25
9
24
23
22
21
20
19
18
2
17
1
16
0
Bit:
Bit:
Slot count at last rising edge of UTC1PPS
15
0
14
0
13
0
12
0
11
0
8
7
6
5
4
3
Sample count at last rising edge of UTC1PPS
The Slot_Sample_UTC1PPS register indicates the value that the slot and sample counters held at
the last rising edge of the UTC1PPS pin.
Slot_Nudge register: 16-bit write only.
C-BUS Address $15
All bits cleared to 0 on reset.
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
Bit:
Slot nudge value (two’s complement)
The Slot_Nudge register is written with the amount that the slot counter is to be adjusted at the
next nudge trigger point.
Sample_Nudge register: 16-bit write only.
C-BUS Address $16
All bits cleared to 0 on reset.
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
Bit:
Sample nudge value (two’s complement)
The Sample_Nudge register is written with the amount that the sample counter is to be adjusted
at the next nudge trigger point (only in manual nudge mode, the Sample_Nudge register is
ignored when in either of the auto nudge modes).
