TDMA Digital Radio Processor
CMX7161
RX Data
TX Data
FS
E
FS
TXENA
RXENA
C
D
RXENA
TXENA
RAMDAC
A
B
C
TX Modulation
Internal Timing
Reference
Figure 15 Timing relationships
7.8
Operating Modes
The CMX7161 can be set into four main operating modes using the Modem Control - $6B, write register:
Sleep mode – for power saving and device configuration
Transmit Data mode – for continuous transmission
Receive Data mode – for continuous reception
Slotted Data mode – for transmission and reception in 30ms slots
A number of test modes are also provided for set-up and calibration.
2013 CML Microsystems Plc
Page 25
