6.3 Page 3 Registers
6.3.1 Voltage Sag and Current Fault Duration Registers ( VSAGDuration , ISAGDuration
)
Address: 6 (Voltage Sag Duration); 10 (Current Fault Duration)
MSB
LSB
22
21
20
19
18
17
16
6
5
4
3
2
1
0
0
.....
2
2
2
2
2
2
2
2
2
2
2
2
2
2
Default = 0x000000
Voltage Sag Duration (VSAGDuration) and Current Fault Duration (ISAGDuration) defines the number of instanta-
neous measurements utilized to determine a sag event. Setting these register to zero will disable this feature.
The value is represented in unsigned notation. See Section 5.6 Sag and Fault Detect Feature on page 19.
6.3.2 Voltage Sag and Current Fault Level Registers ( VSAGLevel , ISAGLevel
)
Address: 7 (Voltage Sag Level ); 11 (Current Fault Level )
MSB
LSB
-1
-2
-3
-4
-5
-6
-7
-17
-18
-19
-20
-21
-22
-23
.....
0
2
2
2
2
2
2
2
2
2
2
2
2
2
2
Default = 0x000000
Voltage Sag Level (VSAGLevel) and Current Fault Level (ISAGLevel) defines the voltage level that the magnitude
of input samples, averaged over the sag duration, must fall below in order to register a sag/fault condition. These
value are represented in unsigned notation and in the range of 0 ≤ VSAGLevel < 1.0, with the binary point to the
right of the third MSB. See Section 5.6 Sag and Fault Detect Feature on page 19.
