CS5463
6.1.20 Control Register ( Ctrl )
Register Address: 28
23
15
7
22
14
6
21
13
5
20
12
19
11
3
18
10
17
9
16
8
STOP
4
2
1
0
INTOD
NOCPU
NOOSC
Default = 0x000000
STOP
Terminates the auto-boot sequence.
0 = Normal (default)
1 = Stop sequence
INTOD
NOCPU
NOOSC
Converts INT output pin to an open drain output.
0 = Normal (default)
1 = Open drain
Saves power by disabling the CPUCLK pin.
0 = Normal (default)
1 = Disables CPUCLK
Saves power by disabling the crystal oscillator.
0 = Normal (default)
1 = Disabling oscillator circuit
6.1.21 Harmonic Active Power Register ( PH
)
Address: 29
MSB
LSB
0
-1
-2
-3
-4
-5
-6
-7
-17
-18
-19
-20
-21
-22
-23
.....
-(2 )
2
2
2
2
2
2
2
2
2
2
2
2
2
2
The Harmonic Active Power (P ) is calculated by subtracting the Fundamental Active Power from the Active
H
(Real) Power. The value is represented in two's complement notation and in the range of -1.0 ≤ P < 1.0, with
H
the binary point to the right of the MSB.
6.1.22 Fundamental Active Power Register ( PF )
Address: 30
MSB
LSB
0
-1
-2
-3
-4
-5
-6
-7
-17
-18
-19
-20
-21
-22
-23
.....
-(2 )
2
2
2
2
2
2
2
2
2
2
2
2
2
2
The Fundamental Active Power (P ) is calculated by performing a discrete Fourier transform (DFT) at the rele-
F
vant frequency on the V and I channels. The results are multiplied to yield fundamental power. The value is rep-
resented in two's complement notation and in the range of -1.0 ≤ P < 1.0, with the binary point to the right of
H
the MSB.
DS678PP1
33
