AT89C5132
Bit
Bit
Number
Mnemonic Description
End of Response Interrupt Flag
Set by hardware at the end of response reception.
Cleared when reading MMINT.
6
5
4
3
2
1
0
EORI
EOCI
EOFI
F2FI
F1FI
F2EI
F1EI
End of Command Interrupt Flag
Set by hardware at the end of command transmission.
Clear when reading MMINT.
End of Frame Interrupt Flag
Set by hardware at the end of frame (stream or block) transfer.
Clear when reading MMINT.
FIFO 2 Full Interrupt Flag
Set by hardware when second FIFO becomes full.
Cleared by hardware when second FIFO becomes empty.
FIFO 1 Full Interrupt Flag
Set by hardware when first FIFO becomes full.
Cleared by hardware when first FIFO becomes empty.
FIFO 2 Empty Interrupt Flag
Set by hardware when second FIFO becomes empty.
Cleared by hardware when second FIFO becomes full.
FIFO 1 Empty Interrupt Flag
Set by hardware when first FIFO becomes empty.
Cleared by hardware when first FIFO becomes full.
Reset Value = 0000 0011b
Table 83. MMMSK Register
MMMSK (S:DFh) – MMC Interrupt Mask Register
7
6
5
4
3
2
1
0
MCBM
EORM
EOCM
EOFM
F2FM
F1FM
F2EM
F1EM
Bit
Number
Bit
Mnemonic Description
MMC Card Busy Interrupt Mask Bit
7
6
5
4
3
MCBM
EORM
EOCM
EOFM
F2FM
Set to prevent MCBI flag from generating an MMC interrupt.
Clear to allow MCBI flag to generate an MMC interrupt.
End Of Response Interrupt Mask Bit
Set to prevent EORI flag from generating an MMC interrupt.
Clear to allow EORI flag to generate an MMC interrupt.
End Of Command Interrupt Mask Bit
Set to prevent EOCI flag from generating an MMC interrupt.
Clear to allow EOCI flag to generate an MMC interrupt.
End Of Frame Interrupt Mask Bit
Set to prevent EOFI flag from generating an MMC interrupt.
Clear to allow EOFI flag to generate an MMC interrupt.
FIFO 2 Full Interrupt Mask Bit
Set to prevent F2FI flag from generating an MMC interrupt.
Clear to allow F2FI flag to generate an MMC interrupt.
101
4173E–USB–09/07
