AT8xC51SND2C
Table 150. MMMSK Register
MMMSK (S:DFh) – MMC Interrupt Mask Register
7
6
5
4
3
2
1
0
MCBM
EORM
EOCM
EOFM
F2FM
F1FM
F2EM
F1EM
Bit
Bit
Number
Mnemonic Description
MMC Card Busy Interrupt Mask Bit
7
6
5
4
3
2
1
0
MCBM
EORM
EOCM
EOFM
F2FM
F1FM
F2EM
F1EM
Set to prevent MCBI flag from generating an MMC interrupt.
Clear to allow MCBI flag to generate an MMC interrupt.
End Of Response Interrupt Mask Bit
Set to prevent EORI flag from generating an MMC interrupt.
Clear to allow EORI flag to generate an MMC interrupt.
End Of Command Interrupt Mask Bit
Set to prevent EOCI flag from generating an MMC interrupt.
Clear to allow EOCI flag to generate an MMC interrupt.
End Of Frame Interrupt Mask Bit
Set to prevent EOFI flag from generating an MMC interrupt.
Clear to allow EOFI flag to generate an MMC interrupt.
FIFO 2 Full Interrupt Mask Bit
Set to prevent F2FI flag from generating an MMC interrupt.
Clear to allow F2FI flag to generate an MMC interrupt.
FIFO 1 Full Interrupt Mask Bit
Set to prevent F1FI flag from generating an MMC interrupt.
Clear to allow F1FI flag to generate an MMC interrupt.
FIFO 2 Empty Interrupt Mask Bit
Set to prevent F2EI flag from generating an MMC interrupt.
Clear to allow F2EI flag to generate an MMC interrupt.
FIFO 1 Empty Interrupt Mask Bit
Set to prevent F1EI flag from generating an MMC interrupt.
Clear to allow F1EI flag to generate an MMC interrupt.
Reset Value = 1111 1111b
Table 151. MMCMD Register
MMCMD (S:DDh) – MMC Command Register
7
6
5
4
3
2
1
0
MC7
MC6
MC5
MC4
MC3
MC2
MC1
MC0
Bit
Bit
Number
Mnemonic Description
MMC Command Receive Byte
Output (read) register of the response FIFO.
7 - 0
MC7:0
MMC Command Transmit Byte
Input (write) register of the command FIFO.
Reset Value = 1111 1111b
155
4341D–MP3–04/05
