Micro-D Filtered
Series M13
Amphenol
Aerospace
.050" contact spacing
Cbꢁ TꢃꢁMꢀNATꢀꢂN TYPꢃ 2 vꢃꢁTꢀCAꢅ PCb
PLUG
RECEPTACLE
*
INTERFACIAL SEAL INCLUDED
A
B
A
B
.308 (7.82)
MAX
.185 (4.70) MAX
.308 (7.82)
MAX
.253 (6.43) MAX
PIN 1
SKT 1
C
C
.186 (4.72) MAX
.190 (4.82) MAX
.198 (5.03) MAX
.190 (4.82) MAX
.600 (15.24) MAX C-FILTER
.900 (22.86) MAX PI-FILTER
.600 (15.24) MAX C-FILTER
.900 (22.86) MAX PI-FILTER
LEAD LENGTH .015
LEAD LENGTH .015
.015 MIN WASHOUT
.020 TYP.
.015 MIN WASHOUT
.020 TYP.
SIZE
A
MAX.
B
C
MAX.
.005 (0.13)
PLUG
RCPT
09
15
21
25
31
37
.785 (19.94)
.935 (23.75)
1.085 (27.56)
1.185 (30.10)
.565 (14.35)
.715 (18.16)
.865 (21.97)
.965 (24.51)
.334 (8.48)
.484 (12.29)
.634 (16.10)
.734 (18.64)
.884 (22.45)
.402 (10.21)
.552 (13.97)
.702 (17.83)
.802 (20.37)
.952 (24.18)
1.102 (27.99)
1.335 (33.91) 1.115 (28.32)
1.485 (37.72) 1.265 (32.13) 1.034 (26.26)
Refer to page 156 for vertical mount PC Configurations (Rear View)
Inches (mm)
All dimensions for reference only
Contact Amphenol Aerospace for more information at 800-678-0141 • www.amphenol-aerospace.com
