Hi-Density Card Connectors
Series 106
Amphenol
Aerospace
wire harness (stranded ꢆire termination)
PLUG
RECEPTACLE
3-PC POLARIZED
A
2-PC POLARIZED
JACKPOST KEY ASSY.
#2-56 UNC-2B THD
(2 PLCS)
JACKSCREW ASSY.
#2-56 UNC-2A THD
(2 PLCS)
A
B
B
C
PIN D1
PIN A1
SKT A1
D1
A1
A1
.150 (3.81)
.050 (1.27)
D1
.296 (7.52) MIN
.025 (.64) TYP
.050 (1.27) TYP
SKT D1
.144
/
/
.130
3.30)
(3.66
C
.295 (7.49) MAX
WIRE LENGTH
+1.00/-0.00
METAL SHELL
DIELECTRIC
INSULATOR
POTTING
WIRE LENGTH
+1.00/-0.00
FLAT HEAD SCREW
#2-56 UNC-2A THD
(2 PLCS)
ALLEN KEY ACCESS
.050 HEX
(2 PLCS)
PLUG
VERTICAL PCB MOUNT (24 AWG WIRE, TIN DIPPED)
RECEPTACLE
A
B
PIN D14
.025 TYP
(0.635)
PIN D1
.050 TYP
(1.27)
A
B
D1
A1
C
.360
(9.144)
.050 (1.27)
.150 (3.81)
SKT A1
A1
PIN A14
PIN A1
.195
(4.953)
JACKSCREW ASSEMBLY
#2-56UNC-2A THD.
2 PL
D1
SKT D1
.296 (7.52) MIN
C
.144
(3.66
/
/
.130
3.30)
.423
(10.744)
.210
(5.334)
.340
(8.636)
.062
.375
D32
C32
D1
C1
A14
B15
A1
B1
.025(0.635) TYP
.050(1.27) TYP
FLAT HEAD SCREW
#2-56 UNC-2A THD
(2 PLCS)
B1
A1
B32
A32
C1
D1
D14
C15
CONSULT AMPHENOL AEROSPACE FOR SPECIFIC PCB CONFIGURATIONS
Inches (mm)
All dimensions for reference only
Contact Amphenol Aerospace for more information at 800-678-0141 • www.amphenol-aerospace.com
181
