Series M13
Amphenol
Aerospace
.050" contact spacing
SꢃꢄꢂD w ꢀ ꢁ Tꢁꢀ MꢂNATꢂꢃN TYPꢁ 5 STꢀ AꢂGHT
RECEPTACLE
PLUG
*
INTERFACIAL SEAL INCLUDED
A
B
A
B
.308 (7.82) MAX
.185 (4.70) MAX
.308 (7.82) MAX
.253 (6.43) MAX
PIN 1
SKT 1
C
C
.186 (4.72) MAX
.198 (5.03) MAX
.350 (8.89) MAX C-FILTER
.650 (16.51) MAX PI-FILTER
.350 (8.89) MAX C-FILTER
.650 (16.51) MAX PI-FILTER
LEAD LENGTH .015
LEAD LENGTH .015
.015 MIN
WASHOUT AREA
.015 MIN
WASHOUT AREA
.020 TYP.
.020 TYP.
.043
.043
.025
.050
.025
.050
C
MAX
A
MAX
B
SIZE
.005 (0.13)
PLUG
RCPT
09
15
21
25
31
37
.785 (19.94)
.935 (23.75)
1.085 (27.56)
1.185 (30.10)
1.335 (33.91)
1.485 (37.72)
.565 (14.35)
.715 (18.16)
.865 (21.97)
.965 (24.51)
1.115 (28.32)
1.265 (32.13)
.334 (8.48)
.484 (12.29)
.634 (16.10)
.734 (18.64)
.884 (22.45)
1.034 (26.26)
.402 (10.21)
.552 (13.97)
.702 (17.83)
.802 (20.37)
.952 (24.18)
1.102 (27.99)
Inches (mm)
All dimensions for reference only
Contact Amphenol Aerospace for more information at 800-678-0141 • www.amphenol-aerospace.com
