Micro-D Filtered
Series M13
Amphenol
Aerospace
.050" contact spacing
bS TꢃꢁMꢀNATꢀꢂN TYPꢃ 1 vꢃꢁTꢀCAꢅ PCb
PLUG
RECEPTACLE
*
INTERFACIAL SEAL INCLUDED
A
B
D
C
A
B
D
C
.308 (7.82)
MAX
.308 (7.82)
MAX
.185 MAX
.253 MAX
E
E
.198 (5.03) MAX
.190 (4.82) MAX
.186 (4.72) MAX
.190 (4.82) MAX
.600 (15.24) MAX C-FILTER
.900 (22.86) MAX PI-FILTER
.600 (15.24) MAX C-FILTER
.900 (22.86) MAX PI-FILTER
.015 MIN WASHOUT
.020 TYP.
.015 MIN WASHOUT
.020 TYP.
LEAD LENGTH
.015
LEAD LENGTH
.015
SIZE
A
MAX.
B
C
D
MAX.
C
MAX.
.005 (0.13)
.005 (0.13)
PLUG
RCPT
09
15
21
25
31
37
1.390 (35.31) 1.150 (29.21)
1.390 (35.31) 1.150 (29.21)
1.690 (43.93) 1.450 (36.83)
1.740 (44.20) 1.500 (38.10)
.565 (14.35)
.715 (18.16)
.785 (19.84)
.935 (23.75)
.334 (8.48)
.484 (12.29)
.634 (16.10)
.734 (18.64)
.884 (22.45)
.402 (10.21)
.552 (13.97)
.702 (17.83)
.802 (20.37)
.952 (24.18)
.865 (21.97) 1.085 (27.56)
.965 (24.51) 1.185 (30.10)
2.040 (51.82) 1.800 (45.72) 1.115 (28.32) 1.335 (33.91)
2.340 (59.44) 2.100 (53.34) 1.265 (32.13) 1.485 (37.72) 1.034 (26.26) 1.102 (27.99)
Refer to page 149 for Vertical Mount PC Configurations (Rear View)
Inches (mm)
All dimensions for reference only
Contact Amphenol Aerospace for more information at 800-678-0141 • www.amphenol-aerospace.com
