EMI Backshells
Series M13
Amphenol
Aerospace
.050" contact spacing
Cbꢀ Tꢁꢀ MꢂNATꢂꢃN TYPꢁ 4 ꢀ ꢂGHT ANGꢄꢁ PCb
PLUG
RECEPTACLE
*
INTERFACIAL SEAL INCLUDED
A
B
A
B
.308 (7.82)
MAX
.185 (4.70) MAX
.020 TYP.
.308 (7.82)
MAX
.253 (6.43) MAX
.020 TYP.
LEAD LENGTH
.015
LEAD LENGTH
.015
C
C
.186 (4.72) MAX
.190 (4.82) MAX
.198 (5.03) MAX
.190 (4.82) MAX
.510 (12.95) MAX C-FILTER
.810 (20.57) MAX PI-FILTER
.510 (12.95) MAX C-FILTER
.810 (20.57) MAX PI-FILTER
.152 FOR SIZE 9-25
.250 FOR SIZE 31 & 37
.152 FOR SIZE 9-25
.250 FOR SIZE 31 & 37
C
M AX
A
M AX
B
SIZE
.005 (0.13)
PLUG
RCPT
09
15
21
25
31
37
.785 (19.94)
.935 (23.75)
1.085 (27.56)
1.185 (30.10)
.565 (14.35)
.715 (18.16)
.865 (21.97)
.965 (24.51)
.334 (8.48)
.484 (12.29)
.634 (16.10)
.734 (18.64)
.884 (22.45)
.402 (10.21)
.552 (13.97)
.702 (17.83)
.802 (20.37)
.952 (24.18)
1.335 (33.91) 1.115 (28.32)
1.485 (37.72)
1.265 (32.13) 1.034 (26.26) 1.102 (27.99)
Refer to page 153 for Right Angle (90 Deg) Narrow Profile PC Configurations
Inches (mm)
All dimensions for reference only
Contact Amphenol Aerospace for more information at 800-678-0141 • www.amphenol-aerospace.com
