Filtered
Series M13
.050" contact spacing
Amphenol
Aerospace
SꢂꢅDꢃꢁ CꢄP TꢃꢁMꢀNATꢀꢂN TYPꢃ 3
*
INTERFACIAL SEAL INCLUDED
A
B
A
B
.308 (7.82) MAX
.185 (4.70) MAX
.308 (7.82) MAX
.253 (6.43) MAX
PIN 1
SKT 1
C
C
REF .093(2.36)
REF .093(2.36)
.198 (5.03) MAX
.186 (4.72) MAX
.125 (2.18) MAX
.370 (9.40) MAX C-FILTER
.670 (17.02) MAX PI-FILTER
.370 (9.40) MAX C-FILTER
.670 (17.02) MAX PI-FILTER
.125 (3.18) MAX
SOLDER CUP ACCOMODATES
26 AWG MAX
SOLDER CUP ACCOMODATES
26 AWG MAX
F
F
REF .285 (7.24)
REF .285 (7.24)
C
MAX
A
MAX
B
F
MAX
SIZE
.005 (0.13)
PLUG
RCPT
09
15
21
25
31
37
.785 (19.94)
.935 (23.75)
1.085 (27.56)
1.185 (30.10)
1.335 (33.91)
1.485 (37.72)
.565 (14.35)
.334 (8.48)
.402 (10.21)
.552 (13.97)
.702 (17.83)
.802 (20.37)
.952 (24.18)
1.102 (27.99)
.400 (10.16)
.550 (13.97)
.700 (17.78)
.800 (20.32)
.950 (24.13)
1.100 (27.94)
.715 (18.16)
.865 (21.97)
.965 (24.51)
1.115 (28.32)
1.265 (32.13)
.484 (12.29)
.634 (16.10)
.734 (18.64)
.884 (22.45)
1.034 (26.26)
Inches (mm)
All dimensions for reference only
Contact Amphenol Aerospace for more information at 800-678-0141 • www.amphenol-aerospace.com
186
