RST must be asserted low to start a NAND tree test se-
quence. Initially, all NAND tree inputs except RST
should be driven high. This will result in a high output
at the INTA pin. If the NAND tree inputs are driven from
high to low in the same order as they are connected to
build the NAND tree, INTA will toggle every time an ad-
ditional input is driven low. INTA will change to low,
when CLK is driven low and all other NAND tree inputs
stay high. INTA will toggle back to high, when GNT is
additionally driven low. The square wave will continue
until all NAND tree inputs are driven low. INTA will be
high, when all NAND tree inputs are driven low. See
Figure 49.
NAND Tree Testing
The controller provides a NAND tree test mode to allow
checking connectivity to the device on a printed circuit
board. The NAND tree is built on all PCI bus pins.
NAND tree testing is enabled by asserting RST. PG
input should be driven HIGH during NAND tree testing.
All PCI bus signals will become inputs on the assertion
of RST. The result of the NAND tree test can be ob-
served on the INTA pin. See Figure 48.
Pin 141 (RST) is the first input to the NAND tree. Pin
142 (CLK) is the second input to the NAND tree, fol-
lowed by pin 143 (GNT). All other PCI bus signals fol-
low, counterclockwise, with pin 61 (AD0) being the last.
Table 21 and Table 22 shows the complete list of pins
connected to the NAND tree.
Some of the pins connected to the NAND tree are out-
puts in normal mode of operation. They must not be
driven from an external source until the controller is
configured for NAND tree testing.
VDD
RST (pin141)
CLK (pin 142)
Am79C978
Core
Am79C972
Core
GNT (pin 143)
....
INTA
S
B
A
INTA (pin 140)
O
MUX
AD0 (pin 61)
22206B-52
Figure 48. NAND Tree Circuitry (160 PQFP)
