Hot Socketing and Power-On Reset in MAX II Devices
1
After SRAM configuration, all registers in the device are cleared
and released into user function before I/O tri-states are released.
To release clears after tri-states are released, use the DEV_CLRn
pin option. To hold the tri-states beyond the power-up
configuration time, use the DEV_OEpin option.
This chapter refereces the following documents:
Referenced
Documents
■
■
DC and Switching Characteristics chapter in the MAX II Device
Handbook
Using MAX II Devices in Multi-Voltage Systems chapter in the MAX II
Device Handbook
Table 4–1 shows the revision history for this chapter.
Document
Revision History
Table 4–1. Document Revision History
DateandDocument
Version
Changes Made
Summary of Changes
December 2007
v2.0
●
Updated “Hot Socketing Feature Implementation in MAX II
Devices” section.
Updated document
with MAX IIZ
●
●
●
Updated “Power-On Reset Circuitry” section.
Updated Figure 4–5.
Added “Referenced Documents” section.
information.
December 2006
v1.5
Added document revision history.
—
—
February 2006
v1.4
●
●
●
Updated “MAX II Hot-Socketing Specifications” section.
Updated “AC and DC Specifications” section.
Updated “Power-On Reset Circuitry” section.
June 2005
v1.3
Updated AC and DC specifications on page 4-2.
—
—
—
December 2004
v1.2
Added content to Power-Up Characteristics section.
Updated Figure 4-5.
June 2004
v1.1
Corrected Figure 4-2.
Altera Corporation
December 2007
4–9
MAX II Device Handbook, Volume 1
