AD5940
Data Sheet
Low Power Mode Configuration Register—LPMODECON
Address 0x00002114, Reset: 0x00000102, Name: LPMODECON
The LPMODECON register is protected by the LPMODEKEY register.
Table 166. Bit Descriptions for LPMODECON Register
Bits
Bit Name
Settings Description
Reset
0x0
0x1
0x0
0x0
0x0
0x0
0x0
0x1
0x0
Access
R
[31:9] Reserved
8
7
6
[5:4]
3
2
Reserved.
ALDOEN
Set this bit high to power-down the analog LDO.
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
V1P1HSADCEN
V1P8HSADCEN
RESERVED
REPEATADCCNVEN_P
ADCCONVEN
HSREFDIS
Set this bit high to enable the 1.11 V high speed common-mode buffer.
Set this bit high to enable the high speed 1.82 V reference buffer.
Reserved.
Set this bit high to enable the repetition of ADC conversions.
Set this bit high to enable ADC conversions.
1
0
Set this bit high to power-down the high speed reference.
Set this bit high to power-down the high speed power oscillator.
HFOSCPD
Rev. 0 | Page 120 of 130
