FEDL87V2107-01
OKI Semiconductor
ML87V2107
•
Setting of Horizontal Read Valid Pixel Start Position (OHPS)
The horizontal read valid data start position (OHPS) is set in pixel unit with reference to the output horizontal
reset (OHR: internal signal), generated from OHS, by setting NPHWE[7:0] (SUB:63h-bit[7:0]).
The data subsequent to OHPS is read from the data memory of valid pixels as the valid data.
This value can be set in 255 levels of (127 pixels with regard to the initial value (NPHWE[7:0] = 80h).
Table F1-2-3(3) Horizontal Read Start Position
HMD
VMD
[0]
OHPS position (number of pixels from OHS)
NPHRE=80h
NPHRE=01h
(−127 Pixels)
17
NPHRE=FFh
(+127 Pixels)
[1]
[0]
……
……
(default)
144
0
0
0
0
1
1
0
0
1
0
1
0
1
……
……
……
……
……
……
……
……
……
……
……
……
271
265
319
299
319
311
0
11
65
45
65
57
138
1
192
1
172
0
192
0
184
Others
Test modes (not settable)
*VMD[1]=0
OHS
127pixels
127pixels
OHPS
1pixel
#ORE
1pixel
640/720/768pixels
Valid data
Memory
output
10pixels
10pixels
HREF
YO[7:0]
CO[7:0]
Valid data
Figure F1-2-3(4) Horizontal Read Start Timing
30/152
