3.9.4.10 Vertical Size of Decoded Image 1 Register (H264F1MYS)
This register indicates the Vertical Size of decoded image in Frame Buffer 1.
Address: FFE0 1C4Ch
Bit
31 : 6
5 : 0
R/W
R
R
Description
Default Value
Reserved
Vertical Size of Decoded Image 1 in MB number
-
0h
3.9.4.11 Horizontal Size of Decoded Image 2 Register (H264F2MXS)
This register indicates the Horizontal Size of decoded image in Frame Buffer 2.
Address: FFE0 1C50h
Bit
31 : 6
5 : 0
R/W
R
R
Description
Default Value
Reserved
Horizontal Size of Decoded Image 2 in MB number
-
0h
3.9.4.12 Vertical Size of Decoded Image 2 Register (H264F2MYS)
This register indicates the Vertical Size of decoded image in Frame Buffer 2.
Address: FFE0 1C54h
Bit
31 : 6
5 : 0
R/W
R
R
Description
Default Value
Reserved
Vertical Size of Decoded Image 2 in MB number
-
0h
3.9.4.13 Horizontal Size of Scaler Output Register (H264XOUTP)
This register sets the Horizontal Size of Scaler output image.
Address: FFE0 1C80h
Bit
31 : 10
9 : 0
R/W
R
R/W
Description
Reserved
Horizontal Size of Scaler output Image
Default Value
-
0h
The Horizontal Size of Scaler Output register configures the Destination Size. This is equivalent to resizing the
Horizontal Size of decoded Image.
3.9.4.14 Vertical Size of Scaler Output Register (H264YOUTP)
This register sets the Vertical Size of Scaler output image.
Address: FFE0 1C84h
Bit
31 : 10
9 : 0
R/W
R
R/W
Description
Reserved
Vertical Size of Scaler output Image
Default Value
-
0h
The Vertical Size of Scaler Output register configures the Destination Size. This is equivalent to resizing the
Vertical Size of decoded Image.
