Cable Assembly Instruction Q
Clamp
STEP 1.
STEP 2.
STEP 3.
STEP 4.
STEP 5.
STEP 1.
STEP 2.
All parts of the connector are shown.
Strip the inner conductor, dielectric, outer conductor, and jacket
as per "RECOMMENDED CABLE STRIPPING DIM'S" in catalog.
STEP 3.
STEP 4.
Thread the GASKET onto the cable until it is against the cable
jacket.
Thread the CLAMP NUT onto the cable until the A dimension
is 1-1.5 mm, then push the TOP HAT onto the outer conductor
of cable inside as shown.
STEP 5.
Thread the MAIN BODY onto the CLAMP NUT and tighten
the connection with wrenches, hold the CLAMP NUT and turn
only the MAIN BODY.
225
