Cable Assembly Instruction O
Twist-on
STEP 1.
STEP 2.
The connector is shown.
Strip the cable inner conductor, dielectric, braid, and jacket as per
"RECOMMENDED CABLE STRIPPING DIM'S" in catalog.
STEP 3.
STEP 4.
STEP 5.
Twist braid in a clockwise direction so that at least 0,8mm of
dielectric is bared, and braid is left flat.
Insert inner conductor into back end of connector gently, and
feed it into the guide hole.
Push and screw connector onto cable in a clockwise direction
until it stops.
