Cable Assembly Instruction U
FCP
STEP 1.
STEP 2.
All parts of the connector are shown.
Strip the cable inner conductor, dielectric, braid, and jacket as per
"RECOMMENDED CABLE STRIPPING DIM'S" in catalog.
STEP 3.
STEP 4.
Slide the FERRULE and SHELL onto cable one by one, and
insert the MAIN BODY into braid and dielectric until it is against
cable jacket. Then crimp the CONTACT PIN as shown.
Slide the SHELL onto the MAIN BODY, and push the FERRULE
until it is against the MAIN BODY. If inner conductor sticks out
beyond the CONTACT PIN, trim it.
