Cable Assembly Instruction N
Clamp-solder
STEP 1.
STEP 2.
All parts of the connector are shown.
Strip the inner conductor, dielectric, and jacket as per
"RECOMMENDED CABLE STRIPPING DIM'S" in catalog.
STEP 3.
STEP 4.
Slide the HEX NUT, WASHER, and GASKET onto cable
one by one.
Place the BRAID CLAMP over braid and push back against
cable jacket. Fold back braid wire as shown, and slide the RING
and REAR INSULATOR against the BRAID CLAMP. Then insert
inner conductor into the CONTACT PIN and solder it.
STEP 5.
Insert cable and parts into the MAIN BODY, then screw the
HEX NUT until it is tightened.
