Cable Assembly Instruction R
Twin Solder-clamp
STEP 1.
STEP 2.
All parts of the connector are shown.
Strip the cable inner conductor, dielectric, and jacket as per
"RECOMMENDED CABLE STRIPPING DIM'S" in catalog.
Then slide the NUT, WASHER, and GASKET onto cable.
STEP 3.
STEP 4.
STEP 5.
STEP 6.
Place the BRAID CLAMP over braid and push back against
cable jacket. Fold back braid wire as shown.
Slide the TOP HAT against the BRAID CLAMP. Then insert
inner conductor into the CONTACT PINs and solder them.
Insert the CONTACT PINs into the INSULATOR until the
INSULATOR is against the TOP HAT.
Insert cable and parts into the MAIN BODY, aligning slot of the
INSULATOR with key in the MAIN BODY. Then screw the NUT
until it is tight.
