a-Si TFT LCD Single Chip Driver
240RGBx320 Resolution and 262K color
ILI9325
SM
GS
Scan Direction
Gate Output Sequence
G320
G319
G317
G318
Even-number
TFT Panel
Odd-number
G1, G2, G3, G4, …,G316
G317, G318, G319, G320
0
0
G4
G2
G3
G1
ILI9325
G320
G318
G319
G317
Even-number
TFT Panel
Odd-number
G320, G319, G318, …,
G6, G5, G4, G3, G2, G1
0
1
G4
G2
G3
G1
ILI9325
G320
G2
Even-number
TFT Panel
G1, G3, G5, G7, …,G311
G313, G315, G317, G319
G319
G1
Odd-number
1
0
G2, G4, G6, G8, …,G312
G314, G316, G318, G320
ILI9325
