a-Si TFT LCD Single Chip Driver
240RGBx320 Resolution and 262K color
ILI9325
i80 18-/16-bit System Bus Interface Timing
(a) Write to register
nCS
RS
nRD
nWR
Write register “index”
Write register “data”
DB[17:0]
(b) Read from register
nCS
RS
nRD
nWR
Write register “index”
Read register “data”
DB[17:0]
i80 9-/8-bit System Bus Interface Timing
(a) Write to register
nCS
RS
nRD
nWR
Write register
“high byte data”
Write register
“low byte data”
“00h”
Write register “index”
DB[17:10]
(b) Read from register
nCS
RS
nRD
nWR
Read register
“high byte data”
Read register
“low byte data”
“00h”
Write register “index”
DB[17:10]
Figure 24 Register Read/Write Timing of i80 System Interface
The information contained herein is the exclusive property of ILI Technology Corp. and shall not be distributed,
reproduced, or disclosed in whole or in part without prior written permission of ILI Technology Corp.
Page 50 of 111
Version: 0.35
