L3M
TXC-03452B
DATA SHEET
Figure 16. STM-1 Add/Drop Bus Interface Timing
t
CYC
t
PWH
DCLK
(INPUT)
t
H(1)
t
SU(1)
DDATA(7-0)
DPAR
(INPUTS)
FIXED
STUFF
H1(2)
TUG-3
H1(1)
TUG-3
FIXED
STUFF
C1(1)
C1(2)
C1(3)
J1
DATA
DATA
H(2)
DATA
t
t
SU(2)
DSPE
(INPUT)
t
H(1)
t
SU(1)
DC1J1
(INPUT)
C1(1)
J1
t
OD(1)
ADATA(7-0)
APAR
(OUTPUTS)
FIXED
STUFF
FOR J1
DATA
t
OD(3)
t
OD(2)
ADD
(OUTPUT)
t
OD(4)
Note: The relationship between J1 and the SPE signals is shown for illustration purposes only,
and will be a function of the pointer offset. For the STM-1 format, there will be one J1 pulse
which indicates the start of the VC-4 that carries the three TUG-3s. The C1 pulse is shown
dotted because the C1 pulse may be provided on the DC1 signal lead. If the DC1 signal
lead is not used, it must be grounded. Shown is TUG-3 A being added to the Add bus.
Parameter
DCLK clock period
Symbol
Min
Typ
Max
Unit
tCYC
--
51.44
50
ns
%
DCLK duty cycle, tPWH/tCYC
40
60
DDATA(7-0) data/DPAR/DC1J1 set-up
tSU(1)
7.0
ns
time to DCLK↓
DDATA(7-0) data/DPAR/DC1J1 hold time
tH(1)
3.0
ns
after DCLK↓
DSPE set-up time to DCLK↓
DSPE hold time after DCLK↓
tSU(2)
tH(2)
10.0
5.0
ns
ns
ns
ADATA(7-0) data and APAR delay after
tOD(1)
3.0
30
DCLK↑
ADD indicator delayed after DCLK↑
tOD(2)
tOD(3)
3.0
12
25
25
ns
ns
ADATA(7-0) data and APAR tri-state after
DCLK↑
ADD high after DCLK↑
tOD(4)
12
25
ns
TXC-03452B-MB
Ed. 6, April 2001
- 36 of 96 -
