MVTX2801
Data Sheet
Bit [3:0]
Bit [7:4]
(Default 4'H2)
Signal polarity:
0: not invert polarity (high true)
1: invert polarity
(Default 4'H3)
Signal Select
0: not select
1: select the corresponding bit
When bits get selected, the led_byteout_[4] = AND (all selected bits)
10.7.18 LEDUSER5/LEDSIG5
2
I C Address:h0C0, Serial Interface Address:h611
Access by CPU, serial interface (R/W)
7
0
LED USER5
Bit [7:0]
(Default 8'H20)
Content will be sent out by LED serial shift logic.
In parallel mode: this register is used for programming the LED pin - led_byteout_[5]
7
4
3
0
COL
FDX
SP1
SP0
COL
FDX
SP1
SP0
Bit [3:0]
Bit [7:4]
(Default 4'H0)
Signal polarity:
0: not invert polarity (high true)
1: invert polarity
(Default 4'H2)
Signal Select:
0: not select
1: select the corresponding bit
When bits get selected, the led_byteout_[5] = AND (all selected bits)
10.7.19 LEDUSER6/LEDSIG6
2
I C Address:h0C1, Serial Interface Address:h612
Access by CPU, serial interface (R/W)
7
0
LED USER6
