Figure 6: CTU transfer to/from a single RBI via the R-bus.
Transfers on other busses are similar and will also produce a response.
Figure 7: CTU transfer to a group of RBls via the l-bus. Transfers on other busses are similar.
A response will only be generated if the R-bus is not used for transfer and the Terminal Address of one
member of the group corresponds to the Programmable Address assigned to the group
Figure 8: RBI transfer to a group of RBls via the BT-bus. Transfers on other busses are similar.
A response will only be generated by the group’s ‘talker’ if the BT-bus is used for transfer.
