Platform Flash In-System Programmable Configuration PROMS
Design Revisioning
Design Revisioning allows the user to create up to four
unique design revisions on a single PROM or stored across
multiple cascaded PROMs. Design Revisioning is sup-
ported for the 8/16/32 Mbit XCFxxP Platform Flash PROMs
in both serial and parallel modes. Design Revisioning can
be used with compressed PROM files, and also when the
CLKOUT feature is enabled. The PROM programming files
along with the revision information files (.cfi) are created
using the iMPACT software. The .cfi file is required to enable
design revision programming in iMPACT.
sions, four 16-Mbit design revisions, and so on. When cas-
cading one 16-Mbit PROM and one 8-Mbit PROM, there are
24 Mbits of available space, and therefore up to three sepa-
rate design revisions can be stored: one 24-Mbit design
revision, two 8-Mbit design revisions, or three 8-Mbit design
revisions.
See Figure 7 for a few basic examples of how multiple revi-
sions can be stored. The design revision partitioning is han-
dled automatically during file generation in iMPACT.
During the PROM file creation, each design revision is
assigned a revision number:
A single design revision is composed of from 1 to n 8-Mbit
memory blocks. If a single design revision contains less
than 8 Mbits of data, then the remaining space is padded
with all ones. A larger design revision can span several
8-Mbit memory blocks, and any space remaining in the last
8-Mbit memory block is padded with all ones.
Revision 0 = '00'
Revision 1 = '01'
Revision 2 = '10'
Revision 3 = '11'
After programming the Platform Flash PROM, a particular
design revision can be selected using the external
REV_SEL[1:0] pins or using the internal programmable
design revision control bits. The EN_EXT_SEL pin deter-
mines if the external pins or internal bits are used to select
the design revision. When EN_EXT_SEL is Low, design
revision selection is controlled by the external Revision
Select pins, REV_SEL[1:0]. When EN_EXT_SEL is High,
design revision selection is controlled by the internal pro-
grammable Revision Select control bits. During power up,
the design revision selection inputs (pins or control bits) are
sampled internally. After power up, when CE is asserted
(Low) enabling the PROM inputs, the design revision selec-
tion inputs are sampled again after the rising edge of the CF
pulse. The data from the selected design revision is then
presented on the FPGA configuration interface.
•
•
•
A single 32-Mbit PROM contains four 8-Mbit memory
blocks, and can therefore store up to four separate
design revisions: one 32-Mbit design revision, two
16-Mbit design revisions, three 8-Mbit design revisions,
four 8-Mbit design revisions, and so on.
Because of the 8-Mbit minimum size requirement for
each revision, a single 16-Mbit PROM can only store
up to two separate design revisions: one 16-Mbit
design revision, one 8-Mbit design revision, or two
8-Mbit design revisions.
A single 8-Mbit PROM can store only one 8-Mbit
design revision.
Larger design revisions can be split over several cascaded
PROMs. For example, two 32-Mbit PROMs can store up to
four separate design revisions: one 64-Mbit design revision,
two 32-Mbit design revisions, three 16-Mbit design revi-
