Philips Semiconductors
Preliminary specification
320 macrocell SRAM CPLD
PZ3320C/PZ3320N
(LZIA). The LZIA is a virtual crosspoint switch that connects the
Logic Blocks to each other and to the GZIA. The feedback from all
80 macrocells, input from the I/O pins, and the 64 bit input bus from
the GZIA are input into the LZIA. The LZIA outputs 36 signals into
each Logic Block and 64 signals into the GZIA.
XPLA2 Fast Module
Each Fast Module consists of four Logic Blocks of 20 macrocells
each. Depending on the package, either 8 or 12 of the 20 macrocells
in each Logic Block are connected to I/O pins, and the remaining
macrocells are used as buried nodes. These four Logic Blocks are
connected together by the Local Zero Power Interconnect Array
MC0
MC0
MC1
MC1
36
20
36
20
LOGIC
BLOCK
LOGIC
BLOCK
I/O
I/O
MC19
MC19
LZIA
MC0
MC1
MC0
MC1
36
20
36
20
LOGIC
BLOCK
LOGIC
BLOCK
I/O
I/O
MC19
MC19
64
64
SP00656
Figure 2. Philips XPLA2 Fast Module
5
1998 Jul 22
