The value in ACTL_RDSTB register is the record destination base address of DMA, and only could be
changed by CPU.
31
23
15
7
30
22
14
6
29
21
13
5
28
AUDIO_RDSTB[31:24]
20 19
AUDIO_RDSTB[23:16]
12 11
AUDIO_RDSTB[15:8]
27
26
18
10
2
25
17
9
24
16
8
4
3
1
0
AUDIO_RDSTB[7:0]
BITS
DESCRIPTIONS
32-bit record destination base address
[31:0]
AUDIO_RDSTB[31:0]
The AUDIO_RDSTB[31:0] bits is read/write.
DMA destination end address (ACTL_RDST_LENGTH)
REGISTER
ADDRESS R/W
DESCRIPTION
RESET VALUE
0xFFF0_900C R/W DMA record destination address length 0x0000_0000
ACTL_RDST_LENGTH
The value in ACTL_RDST_LENGTH register is the record destination address length of DMA, and the
register could only be changed by CPU.
31
23
15
7
30
22
14
6
29
21
13
5
28
AUDIO_RDST_L[31:24]
20 19
AUDIO_RDST_L[23:16]
12 11
AUDIO_RDST_L[15:8]
27
26
18
10
2
25
17
9
24
16
8
4
3
1
0
AUDIO_RDST_L[7:0]
