W83697HF/F
Bank 4
9.7.43 Real Time Hardware Status Register I -- Index 59h (
)
Register Location:
Power on Default Value 00h
Attribute:
59h
Read Only
8 bits
Size:
7
6
5
4
3
2
1
0
VCORE_STS
Reserved
+3.3VIN_STS
AVCC_STS
TEMP1_STS
TEMP2_STS
FAN1_STS
FAN2_STS
Bit 7: FAN 2 Status. Set 1, the fan speed counter is over the limit value. Set 0, the fan speed counter
is in the limit range.
Bit 6: FAN 1 Status. Set 1, the fan speed counter is over the limit value. Set 0, the fan speed counter
is in the limit range.
Bit 5: Temperature sensor 2 Status. Set 1, the voltage of temperature sensor is over the limit value.
Set 0, the voltage of temperature sensor is in the limit range.
Bit 4: Temperature sensor 1 Status. Set 1, the voltage of temperature sensor is over the limit value.
Set 0, the voltage of temperature sensor is in the limit range.
Bit 3: AVCC Voltage Status. Set 1, the voltage of +5V is over the limit value. Set 0, the voltage of +5V is
in the limit range.
Bit 2: +3.3V Voltage Status. Set 1, the voltage of +3.3V is over the limit value. Set 0, the voltage of
+3.3V is in the limit range.
Bit 1: Reserved
Bit 0: VCORE Voltage Status. Set 1, the voltage of VCORE A is over the limit value. Set 0, the
voltage of VCORE A is in the limit range.
Bank 4
9.7.44 Real Time Hardware Status Register II -- Index 5Ah (
)
Register Location:
Power on Default Value 00h
Attribute:
5Ah
Read Only
8 bits
Size:
Publication Release Date: Feb. 2002
Revision 0.70
- 122 -
