W83697HF/F
Bank 1
9.7.35 Temperature Sensor 2 Over-temperature (Low Byte) Register - Index 56h (
)
Register Location:
Power on Default Value 00h
Attribute:
56h
Read/Write
8 bits
Size:
7
6
5
4
3
2
1
0
Reserved
TOVF2<0>
Bit 7: Over-temperature bit 0, which is low Byte.
Bit 6-0: Reserved.
9.7.36 Interrupt Status Register 3 -- Index 50h (BANK4)
Register Location:
Power on Default Value 00h
Attribute:
50h
Read Only
8 bits
Size:
7
6
5
4
3
2
1
0
5VSB
VBAT
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Bit 7-2: Reserved.
Bit 1: A one indicates a High or Low limit of VBAT has been exceeded.
Bit 0: A one indicates a High or Low limit of 5VSB has been exceeded.
Publication Release Date: Feb. 2002
Revision 0.70
