W83697HF/F
Bank 1
9.7.33 Temperature Sensor 2 Hysteresis (Low Byte) Register - Index 54h (
)
Register Location:
Power on Default Value 00h
Attribute:
54h
Read/Write
8 bits
Size:
7
6
5
4
3
2
1
0
Reserved
THYST2<0>
Bit 7: Hysteresis temperature bit 0, which is low Byte.
Bit 6-0: Reserved.
Bank 1
9.7.34 Temperature Sensor 2 Over-temperature (High Byte) Register - Index 55h (
)
Register Location:
Power on Default Value
Attribute:
55h
50h
Read/Write
8 bits
Size:
7
6
5
4
3
2
1
0
TOVF2<8:1>
Bit 7-0: Over-temperature bit 8-1, which is High Byte. The temperature default 80 degree C.
