W83697HF/F
7
6
5
4
3
2
1
0
+12VIN_STS
-12VIN_STS
-5VIN_STS
Reserved
CASE_STS
Reserved
Reserved
Reserved
Bit 7-6: Reserved
Bit 5: Reserved
Bit 4: Case Open Status. Set 1, the case open sensor is sensed the high value. Set 0
Bit 3: Reserved
Bit 2: -5V Voltage Status. Set 1, the voltage of -5V is over the limit value. Set 0, the voltage of -5V is
during the limit range.
Bit 1: -12V Voltage Status. Set 1, the voltage of -12V is over the limit value. Set 0, the voltage of - 12V is
during the limit range.
Bit 0: +12V Voltage Status. Set 1, the voltage of +12V is over the limit value. Set 0, the voltage of +12V
is in the limit range.
Bank 4
9.7.45 Real Time Hardware Status Register III -- Index 5Bh (
)
Register Location:
Power on Default Value 00h
Attribute:
5Bh
Read Only
8 bits
Size:
7
6
5
4
3
2
1
0
5VSB_STS
VBAT_STS
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Bit 7-2: Reserved.
Bit 1: VBAT Voltage Status. Set 1, the voltage of VBAT is over the limit value. Set 0, the voltage of
VBAT is during the limit range.
Bit 0: 5VSB Voltage Status. Set 1, the voltage of 5VSB is over the limit value. Set 0, the voltage of
5VSB is in the limit range.
Publication Release Date: Feb. 2002
- 123 -
Revision 0.70
