W83697HF/F
Bank 0
9.7.27 Reserved Register -- 5Eh (
)
Bank 0
9.7.28 Reserved Register-- 5Fh (
)
Bank 1
9.7.29 Temperature Sensor 2 Temperature (High Byte) Register - Index 50h (
)
Register Location:
Attribute:
50h
Read Only
8 bits
Size:
7
6
5
4
3
2
1
0
TEMP2<8:1>
°
Bit 7: Temperature <8:1> of sensor 2, which is high byte, means 1C.
Bank 1
9.7.30 Temperature Sensor 2 Temperature (Low Byte) Register - Index 51h (
)
Register Location:
Attribute:
51h
Read Only
8 bits
Size:
7
6
5
4
3
2
1
0
Reserved
TEMP2<0>
°
Bit 7: Temperature <0> of sensor2, which is low byte, means 0.5 C.
Bit 6-0: Reserved.
Publication Release Date: Feb. 2002
Revision 0.70
- 116 -
