W83697HF/F
Bank 0
9.7.21 Chip ID -- Index 58h (
Register Location:
Power on Default Value
Attribute:
)
58h
60h
Read Only
8 bits
Size:
7
6
5
4
3
2
1
0
CHIPID
Bit 7: Winbond Chip ID number. Read this register will return 60h.
Bank 0
9.7.22 Reserved Register -- Index 59h (
)
Register Location:
Power on Default Value
Attribute:
59h
<7>=0 and <6:4> = 111 and <3:0> = 0000
Read/Write
8 bits
Size:
7
6
5
4
3
2
1
0
Reserved
Reserved
Reserved
Reserved
SELPIIV1
SELPIIV2
Reserved
Reserved
Bit 7-6: Reserved
Bit 5: Temperature sensor diode 2. Set to 1, select CPU compatible Diode. Set to 0 to select 2N3904
Bipolar mode.
Bit 4: Temperature sensor diode 1. Set to 1, select CPU compatible Diode. Set to 0 to select 2N3904
Bipolar mode.
Bit 3-0: Reserved
