表 7-139. FLAG_ERR Register Field Descriptions
Bit
Field
Type
Reset
Description
7
FLAG_LOWSUP
FLAG_SUPUV
FLAG_REF
R
0h
Supply voltage low flag
0h = Supply voltage is above preset threshold.
1h = Supply voltage is below preset threshold.
6
5
4
3
2
1
0
R
R
R
R
R
R
R
0h
0h
0h
0h
0h
0h
1h
Supply undervoltage fault flag
0h = No supply undervoltage fault is detected.
1h = Device has supply undervoltage fault detected.
REF pin fault flag
0h = No REF pin fault is detected.
1h = Device has REF pin fault detected.
FLAG_PRETSD
FLAG_TSD
Overtemperature Pre warning flag
0h = No overtemperature pre-warning is detected.
1h = Device has triggered overtemperature pre-warning threshold.
Thermal shutdown flag
0h = No thermal shutdown fault is triggered.
1h = Device has triggered thermal shutdown fault.
FLAG_EEPCRC
FLAG_OUT
EEPROM CRC failure flag
0h = EEPROM CRC passes.
1h = EEPROM CRC fails.
Output fault flag
0h = No output fault is detected.
1h = Device has at least one fault detected on output channels.
FLAG_ERR
Error flag
0h = No error flag.
1h = Device has at least one error flag.
7.6.5.2 FLAG_STATUS Register (Offset = A1h) [Reset = 01h]
FLAG_STATUS is shown in 图 7-132 and described in 表 7-140.
Return to the Summary Table.
图 7-132. FLAG_STATUS Register
7
6
5
4
3
2
1
0
FLAG_EEPPAR FLAG_EXTFS1 FLAG_EXTFS0 FLAG_PROGD
ONE
FLAG_FS
R-0h
FLAG_ADCDO FLAG_ADCER
FLAG_POR
NE
R
R-0h
R-0h
R-0h
R-0h
R-0h
R-0h
R-1h
表 7-140. FLAG_STATUS Register Field Descriptions
Bit
Field
Type
Reset
Description
7
6
5
4
3
FLAG_EEPPAR
FLAG_EXTFS1
FLAG_EXTFS0
FLAG_PROGDONE
FLAG_FS
R
0h
EEPROM parity error flag
0h = No internal EEPROM parity error is triggered.
1h = Internal EEPROM parity error is triggered.
R
R
R
R
0h
0h
0h
0h
FS1 input status flag
0h = FS1 input is logic low.
1h = FS1 input is logic high.
FS0 input status flag
0h = FS0 input is logic low.
1h = FS0 input is logic high.
EEPROM program completition flag
0h = EEPROM burning is not completed or not started.
1h = EEPROM burning is completed.
FS state flag
0h = Device is not in Fail-safe state.
1h = Device is in Fail-safe state.
